5A06 Aluminum Round Rar

Chemical composition of 5A06 aluminum alloy

●Aluminum (Al): balance
●Magnesium (Mg): 5.8-6.8%
●Chromium (Cr): -%
●Manganese (Mn): 0.5-0.8% max
●Copper (Cu): 0.1% max
●Iron (Fe): 0.4% max
●Zinc (Zn): 0.2% max
●Silicon (Si): 0.4% max
●Titanium (Ti): 0.02-0.1% max
●Other elements: Each 0.05% max, Total 0.1% max

Typical mechanical properties of 5A06 H112 aluminum

 (The values are typical or min values,for reference only.)

5A06   H112 aluminum round bar application

5A06 H112 aluminum round bar is part of the 5000-series aluminum-magnesium alloys, which are known for their high strength, excellent corrosion resistance, and good weldability. This alloy is particularly suitable for applications where strength, durability, and resistance to harsh environments are essential. The H112 temper indicates that the alloy is in a work-hardened state with limited heat treatment, designed to maintain a balance between strength and workability.

Common Applications of 5A06 H112 Aluminum Round Bar:

1.Marine Applications:
5A06 aluminum round bar is commonly used in the marine industry due to its outstanding resistance to corrosion in saltwater environments. It is frequently employed in the production of boat hulls, deck structures, marine fittings, and offshore platforms. Its ability to withstand the harsh marine environment makes it an excellent choice for long-term maritime use.

2.Welded Structures:
The high weldability of 5A06 H112 aluminum makes it suitable for large, welded structures such as storage tanks, pressure vessels, and chemical containers. It retains its mechanical properties after welding, which is essential for applications that involve structural integrity and seam strength.

3.Aircraft and Aerospace:
While 5A06 aluminum is not as strong as some aerospace alloys, it is still used in certain non-critical aircraft components where corrosion resistance and durability are more important than extreme strength. Its lightweight nature makes it useful for aircraft skin, fuel tanks, and other structural components in both aircraft and aerospace equipment.

4.Automotive and Transportation:
This alloy is used in the automotive industry for the production of lightweight vehicle components, including chassis parts, reinforcements, truck frames, and railway equipment. The combination of lightweight and strength helps improve fuel efficiency and vehicle performance while ensuring durability in extreme conditions.

5.Construction and Architecture:
Due to its strength, corrosion resistance, and formability, 5A06 H112 aluminum round bar is used in the construction of bridges, structural beams, railings, and exterior building elements. The alloy is particularly favored in environments where it will be exposed to moisture and corrosive elements, making it an ideal material for outdoor structural components.

6.Pressure Vessels and Storage Tanks:
The alloy is used to manufacture pressure vessels, fuel tanks, and liquid storage tanks due to its ability to handle high-pressure environments and resistance to corrosion. Its non-toxic nature makes it suitable for food-grade tanks and chemical containers.

7.Pipelines and Industrial Equipment:
5A06 aluminum round bar is also used in pipelines, heat exchangers, and other industrial equipment where corrosion resistance and high strength are required. It is particularly effective in environments exposed to chemicals or high humidity.

8.Railway Industry:
The alloy is ideal for use in railway carriages, train components, and platform structures due to its lightweight and high durability. Its ability to withstand the mechanical stress of frequent use while maintaining low maintenance requirements makes it an excellent choice for railway applications.

Conclusion:

5A06 H112 aluminum round bar is a versatile and durable material that finds applications across various industries, including marine, aerospace, construction, automotive, and industrial equipment. Its high corrosion resistance, good weldability, and strength make it especially suitable for use in environments that experience extreme conditions, ensuring long-term performance and reliability.
